SS-HSTRBT-380/390
MOQ: 100 Pieces
Delivery time: 7 Day
Equipment function: it can achieve laser double-sided and single-sided marking, fixed length cutting ofcasing,and piercing and drying.
Save consumables for 5 vears or so: Different casing specifications(Φ2-22) The round and flat pipesare universal and easy to replace, The cutting length and production quantity can be adiusted throughparameters; The contents of double-sided marking can be changed instantly through the screen.
Scope of application: For wire harness products that require marking, sleeve piercing and drying arebasically applicable.
Product Details
Applicable wire range
Technical parameter
| Model | SS-HMG-380/390 (380 single-head upgradeable to 390) |
| Power supply | AC 220V 50/60Hz |
| Casinglength | 8MM-50MM |
| Casing diameter | Ф2.0-Ф22 (round tubes, flat tubes) |
| accuracy | ±0.5mm |
| Efficiency | 400-500 (depending on tube length and marking content) |
| Yield rate | 99% (assuming operator is properly trained and skilled) |
| power | 3KW |
| Product size | 1.3m*1.3m*1.5m (L*W*H) |
| Product weight | 290Kg |
